Inspecting missing type chip bonder counter SMD
Information:
Details



SMD Component Counter

 一、Introduction

1Theory

Chip bonder counter can precisely count the SMD quantity, by adopting optical and electric sensor theory, using the corresponding relation between guide hole on the carrier and part, and by the special die and massive integrated circuit, chip bonder counter achieve zero error, and achieve convenient, quick counting, it is an effective auxiliary equipment for managing SMT material.

2Product features

With full automatic way figure part quantity, it is convenient to count and delivery material. Easily operate it, original design defending strip dropping off decrease strip hurt to a smallest extent. It can count in forward direction or in backward direction, and it can be preset value, precisely figure out quantity with zero error. You also can install scanner gun and barcode printer, which is more convenient for managing operation..

3product specification

Power: AC220V50/60HZ25W

Counter range: -99999--99999PCS

Profile size: L470*W300*H180mm

Weight: 10KG

4Product Utility

      Suit for SMD strip type of part
      Strip wheel diameter: suit for any size

      Strip pitch: 124810121624324456mm ( Note: if pitch is smaller or wider, make it according  to customer’s request.
Strip width: 468121624324456mm (Note: if width is smaller or wider, make it according to customer’s request)

5Product Structure:Inspecting missing type chip bonder counter
