Oxygen Analyzer Model RF-30

Features：
● Low cost    3/5 for Our Model RF-800

● Compact Design and Easy Operation ： The size Greatly reduced, 1/4 of RF-800 size,  A big LED display and Operation Keys.

● Easy Sensor Replacement ： Sensor Unit Assembled

●Super Fast Response  Minimum gas build-up on Sampling Line

●Long Service Life Sensor with built-in filter, (Patent Pending)

●Visible check for Replacement Period of Activated Carbon Filter using Bar Graph Display

●4- Types of Alarm for O₂ concentration

●Gas flow Error signal  Float Clog Free for Re-Flow Application  More Reliable due to Detection of the Flow Velocity.

Measurement Principle

Toray’s Zirconia Oxygen analyzers determine oxygen concentration using the conductivity of a zirconia ceramic cell. Ziconia ceramic cell only allows oxygen ions to pass through at high temperatures. With reference gas on one side and sample gas on the other, oxygen ions move from the side with the highest concentration of oxygen to with the lowest concentration. The movement of ions generates an Electro Motive Force, so called Nernst Equation, which can be measured to determine the oxygen content.
